目前市場上的羅茨鼓風機多為三葉式。三葉羅茨鼓風機采用兩組三葉葉輪，每轉動一次完成 3 次吸氣和排氣。它屬于容積式風機，是一種定容旋轉的氣動力機器，具有結構簡單、性能穩定的特點。

　　At present, most Roots blowers on the market are three bladed. The three bladed Roots blower uses two sets of three bladed impellers, with each rotation completing three suction and exhaust operations. It belongs to the positive displacement fan, which is a fixed volume rotating pneumatic machine with the characteristics of simple structure and stable performance.

　　羅茨鼓風機選型技巧

　　Selection Techniques for Roots Blowers

　　1、挑選

　　1. Select

　　在為污水處理廠挑選羅茨鼓風機時，相關產品樣本上顯示的是其在標準進氣狀態下的性能參數。但羅茨鼓風機在實際使用中并非處于標準狀態，當使用環境的溫度、大氣壓、海拔高度等條件不同時，風機的性能也會隨之改變。因此，產品樣本上的性能參數不能在設計和挑選時直接采用，而是需要根據實際使用狀態，將風機的性能要求轉換為標準進氣狀態下的參數后再使用。

　　When selecting Roots blowers for sewage treatment plants, the performance parameters displayed on the relevant product samples are under standard intake conditions. However, Roots blowers are not in a standard state in practical use. When the temperature, atmospheric pressure, altitude and other conditions of the operating environment are different, the performance of the blower will also change accordingly. Therefore, the performance parameters on the product sample cannot be directly used in design and selection. Instead, the performance requirements of the fan need to be converted into parameters under standard intake conditions based on actual usage before use.

　　2、壓力

　　2. Pressure

　　容積式羅茨鼓風機的排氣壓力并不由其自身決定，而是由風機排出氣體后裝置的情況，即所謂的 “背壓” 來確定。曝氣鼓風機具有強制送風的特點，羅茨鼓風機銘牌上標注的排氣壓力是其額定排氣壓力。實際上，只要強度和排氣溫度允許，羅茨鼓風機既可以在低于額定排氣壓力的任意壓力下工作，也能在高于額定排氣壓力的情況下運行。

　　The exhaust pressure of a positive displacement Roots blower is not determined by itself, but by the condition of the device after the fan exhausts the gas, known as the "back pressure". The aeration blower has the characteristic of forced air supply, and the exhaust pressure marked on the nameplate of the Roots blower is its rated exhaust pressure. In fact, as long as the strength and exhaust temperature allow, Roots blowers can operate at any pressure below the rated exhaust pressure or above the rated exhaust pressure.

　　對于污水處理廠而言，排氣系統產生的背壓是管道系統壓力損失值、曝氣池水深與環境大氣壓力的總和。

　　For sewage treatment plants, the back pressure generated by the exhaust system is the sum of the pressure loss value of the pipeline system, the water depth of the aeration tank, and the ambient atmospheric pressure.

　　3、風量（需氧量）

　　3. Air volume (oxygen demand)

　　在計算污水處理需氧量時，得出的結果是標準狀態下所需氧氣的質量流量 qm（kg/min），之后再換算成標準狀態下所需空氣的體積流量 qv1（m/min）。如果羅茨鼓風機的使用狀態并非標準狀態，比如在高原地區，空氣密度和水分含量會發生變化，此時羅茨鼓風機提供的風量流量雖與標準狀態相同，但供給空氣的質量流量會有所下降。

　　When calculating the oxygen demand for sewage treatment, the result obtained is the mass flow rate qm (kg/min) of oxygen required under standard conditions, which is then converted into the volume flow rate qv1 (m/min) of air required under standard conditions. If the usage state of the Roots blower is not standard, such as in high-altitude areas, the air density and moisture content will change. At this time, although the air flow rate provided by the Roots blower is the same as the standard state, the mass flow rate of the supplied air will decrease.

　　4、冬夏的區別

　　4. The difference between winter and summer

　　挑選風機時，要留意其送風量的變化規律。對于同一臺羅茨鼓風機，冬夏兩季的體積流量不會改變，但由于空氣密度不同，質量流量會有所差異，也就是供氧量不同。這是因?yàn)槎練鉁亟档?，空氣密度增大，所以風機供給的干燥空氣質量流量比標準狀態下有較大增加，進而使供氧量增多。

　　When selecting a fan, pay attention to the variation pattern of its air supply volume. For the same Roots blower, the volumetric flow rate in winter and summer will not change, but due to different air densities, the mass flow rate will differ, that is, the oxygen supply will be different. This is because the winter temperature decreases and the air density increases, so the dry air mass flow rate supplied by the fan is significantly increased compared to the standard state, thereby increasing the oxygen supply.

　　因此，在生產運行過程中，需要針對這種變化及時調整設備，讓羅茨鼓風機的充氧能力與實際運行中的需氧量相匹配。對于羅茨鼓風機來說，使用變頻器通過改變風機轉速來調節送風量，是一種經濟實用的方式。

　　Therefore, in the production and operation process, it is necessary to adjust the equipment in a timely manner to match the oxygenation capacity of the Roots blower with the actual oxygen demand during operation. For Roots blowers, using a frequency converter to adjust the air supply by changing the fan speed is an economical and practical way.
